Smart Lock Gateway TTLock, Wi-Fi, Bluetooth

TTLock Wi-Fi/Bluetooth Gateway for Electronic Locks


Features:
The device is designed to connect compatible TTLock Bluetooth electronic locks to the internet via a Wi-Fi network.
It acts as an intermediary communication device between the Bluetooth electronic lock and the internet, so the lock itself does not require a direct Wi-Fi connection.
One gateway can connect up to 3 compatible electronic locks located within 15 m of the gateway (with no obstacles).
Using this gateway, you can remotely unlock a compatible lock, manage access permissions and passwords, synchronize and view unlocking records, check the lock status, and use other remote control functions supported by the specific lock.
The device provides a stable Wi-Fi and Bluetooth connection, features low power consumption, and is designed for long-term operation.
The device is easy to set up and takes only a few minutes. It connects to a 2.4 GHz Wi-Fi network.
To ensure a stable connection with the door lock, it is recommended to install the gateway within 15 metres of the lock, preferably without walls or other obstacles between the devices.


Technical specifications:
Wireless technology: Wi-Fi + Bluetooth.
Wi-Fi frequency: 2.4 GHz.
Wi-Fi standard: IEEE 802.11 b/g/n.
Power supply: DC 5 V / 500 mA.
Power connector: USB Type-C.
LED indicator: 1, dual-colour.
Bluetooth range: up to 10 m without obstacles.
App: TTLock (Android, iOS).
Power cable: USB Type-A to USB Type-C, 1 m long (included).
Dimensions: 70 x 70 x 26 mm.
Weight: 40 g.
Housing material: ABS plastic.
Colour: white.
Certifications: CE, RoHS, UKCA.


Warranty: 24 months.
